04563126
JUMO 55808 Widerstandsthermometer, Bajonett,

The pluggable resistance thermometer with bayonet lock and connecting cable allows, due to the temperature dependence of the electrical resistance of its built-in platinum sensor, a temperature measurement on solids. The protection tube is made of ceramic KER 221 and has a 120° angle at the tip. The dimensions are 6 x 20 mm. The bayonet lock has a diameter of 12 mm. The resistance thermometer is therefore preferably used for temperature measurements on slide bearings and tools in the plastics industry. The resistance thermometer according to DIN EN 60751 (class B) is designed as 1 x Pt100 in two-wire circuit and is designed for temperatures from -50 to +260 °C. The 2.5 m long connection cable made of metal braiding has shielded contacts and is strain-relieved at the transition. The adjustment range of the installation length is 20 to 190 mm. The permissible ambient temperature of the connection cable is -50 to +350 °C. The open connection end is equipped with 6.3 mm receptacles according to DIN 46247.
