03590703
JUMO 00064003 Widerstandsthermometer

Schutzart IP20, Messeinsatz: 1x Pt 100 in Zweileiterschaltung, Typenzusätze: 1x Messumformer analog, Ausgang 4..20mA (in Verbindung mit 1x Pt100) The screw-on resistance thermometer allows, due to the temperature dependence of the electrical resistance of its built-in platinum sensor and the special housing design, temperature measurements in many indoor areas of air conditioning technology. The housing with protection class IP20 consists of PC plastic and is designed for temperatures from -30 to +80 °C. The resistance thermometer is therefore preferably used for temperature measurements in dry rooms. The resistance thermometer according to DIN EN 60751 (class B) is designed as 1 x Pt100 in two-wire circuit. The built-in analog measuring transducer supplies a standardized signal with 4 to 20 mA for the measuring range 0 to 40 °C.
